Lone Rider MotoCAN® V2
Lone Rider

17870-LON-LRMV-MOTBMWR13RAN

Lone Rider MotoCAN® V2

$480.00
Model : BMW R1300GS/Adventure Range
Quantity
In stock

  • Free Shipping above $38

  • Buy Now, Pay Later Available

Top-rated in Singapore. Buy with confidence.

DESCRIPTION

Motorcycle Accessories Manager

The MotoCAN V2 is designed to be directly connected to your motorcycle, interfacing with its CAN-bus system. This offers an incredibly adaptable and effortless plug-and-play solution for incorporating additional components to your bike including Motorcycle Lights MTL9 and MTL4, and other Lone Rider accessories.

FULL CONTROL FROM YOUR SMARTPHONE

The MotoCAN V2 connects directly to your motorcycle's CANbus without cutting a single wire.

Set up and customize everything through the Lone Rider app over Bluetooth:

  • Halo color & intensity
  • Day and Night intensity modes
  • Cornering Lights
  • Dynamic Speed Activation
  • Live diagnostics + OTA firmware updates
  • Individually controlled pod sets



Effortless plug-and-play solution

The MotoCAN® v2 is designed to be directly connected to your motorcycle, interfacing with its CAN-bus system. This offers an incredibly adaptable and effortless plug-and-play solution for incorporating additional components to your bike including Motorcycle Lights. This eliminates the necessity of wire cutting, which could potentially invalidate your warranty. With the MotoCAN v2, you gain the ability to securely oversee your accessories, personalize your motorcycle, and enhance its safety for a smoother riding experience. Lone Rider MotoCAN v2 can power and control Motorcycle Lights and other motorcycle accessories. Upgrade to control lights and other accessories automatically and directly from the bikes button clusters.

MotoCAN v2 is a Plug-in-Play solution to seamlessly control:

  • Motorcycle Lights
  • LIN Smart Lights
  • Auxiliary Lights
  • Brake Lights
  • Air Horns
  • GPS Navigation
  • Dash Cams
  • Heated Gear
  • Air Compressor
  • USB Chargers
  • And other accessories

MotoCAN stands out from other CANBUS devices as has been programmed to get the full range of Motorcycle Lights features and functions. These extended features and functions are compatible with MotoCAN v2 and Motorcycle Lights.



Key Features

One device controls all functions

Unified system management

Adds enhanced safety features

Maintains manufacturer warranty

Connects directly to the CAN-Bus

Discreet design – fits seamlessly under the seat

Simple software setup via Bluetooth or USB-C

Four independently fused electronic channels

Waterproof and dust-resistant

Motorcycle Lights Compatible

LIN compatible on all channels

4x 10A outputs (25A, max 20s)

Self-resettable electronic fuses

3-wire brightness control



MotoCAN v2 Hardware specifications Value
Voltage supply 9V to 18V (12V motorcycle system), brown-out protected
System fuse rating 40A automotive blade fuse, inline at the battery
Maximum continuous current 40A total, fuse-limited
Current consumption (operating) 60mA typical (unit only, lights excluded)
Current consumption (sleep) 0.6mA typical
Number of output circuits Four, each with switched 12V power, ground and light-pod data wire
Output circuit current Outputs 1 and 2 15A continuous, 22A peak. Outputs 3 and 4 12A continuous, 15A peak
Output circuit fusing Electronic smart fuse per output with current monitoring, automatic retry after cool-down, latched off after repeated faults. Trip points fixed per output
Output modes Light pods, Aux light (follows the bike's beams), Ignition, Switch, LED (dimmable), Heat (dimmable, engine-gated), Horn
Output current measurement range 0 to 22A per output
Supply voltage measurement range 0 to 18V
Internal thermal protection Automatic output reduction above 82°C internal temperature, full power restored below 75°C
Transient protection Automotive grade
CAN connectivity 1x CAN 2.0B with wake-on-CAN standby. Bike-specific harness, keyed 2-pin connector
Light connectivity LIN master to Lone Rider MotoLights MTL9 and MTL4. Up to four pods, mixed products, automatic discovery. Pods work on any of the four outputs
Wireless connectivity Bluetooth Low Energy, encrypted and paired. All configuration, diagnostics and firmware updates are wireless from the Lone Rider app
USB connectivity USB-C, for factory and deep service diagnostics only. Not needed by the rider or the installer
Status indication Green LED power. Blue LED Bluetooth link. Both off deep sleep
Water and dust protection Sealed CNC aluminium enclosure, waterproof connectors
Firmware Field-updatable over the air, free
